FEATURES
- Simple installation and setup
- Back lit for easy visibility
- Up to 200 apartments *(by model)
- 2 phone numbers per apartment
- Easy access: Up to 1000 additional caller ID numbers and 2000 (4 digit) PIN codes
- 2 relay outputs / 2 alarm inputs
- Up to 20,000 log events
- Supports 4G-GSM wireless carrier
SPECIFICATIONS
- Mounting: Post or Surface
- Format: Wiegand 26-bit input / output
- Power Supply: 14.4/24 VDC 12-16 VAC
- Current Consumption: Transmitting Mode 330 mA / 14 VDC Idle Mode 360 mA /14 VDC
- Unit Dimensions 11-7/16 x 4-7/16 x 2-3/16”
- External Patch Antenna SMA 1
- Front Plate is Grade 304 Stainless Steel
